Construction waste, construction scraps, bricks and tiles, cans, coal, salt, cement clinker, coal gangue, shale, limestone, bluestone, weathered stone, slag and various ores of medium and low hardness
The finished material of the mobile hammer crusher is cubic, with strong compressive capacity, and is suitable for high-standard construction needs. Maintenance and power saving costs are 50%-70% lower than ordinary crushers.
Novel design, stable and reliable operation, compact structure and few wearing parts.
It is easy to move and can crush materials anytime and anywhere.
The process is simplified and the structure is simple.
Large production capacity, environmental protection and energy saving.
The motor drives the rotor to rotate at high speed in the crushing chamber. The material is fed into the machine from the upper feeding port, and is crushed by the impact, impact, shearing and grinding of the high-speed hammer. In the lower part of the rotor, there is a sieve plate, and the particle size smaller than the sieve hole size in the crushed material is discharged through the sieve plate, and the coarse particle size larger than the sieve hole size is retained on the sieve plate and continues to be hit and ground by the hammer, and finally passes through the sieve plate. out of the machine. If you need to change the site for production, you can activate the mobile device at any time to transfer the equipment to facilitate the production again.
Model | Feed size (mm) | Output size (mm) | Capacity (t/h) | Rotation speed (rpm) | Power (kw) | Weight (ton) | Dimension (mm) |
PCH0402 | ≤200 | ≤30 | 44785 | 960 | 5.5 | 0.8 | 810*890*560 |
PCH0404 | ≤200 | ≤30 | 16-25 | 970 | 11 | 1.05 | 980*890*570 |
PCH0604 | ≤200 | ≤30 | 22-33 | 970 | 15 | 1.43 | 1050*1270*800 |
PCH0606 | ≤200 | ≤30 | 30-60 | 980 | 30 | 1.77 | 1350*1270*1080 |
PCH0808 | ≤200 | ≤30 | 70-105 | 740 | 45 | 3.6 | 1750*1620*1080 |
PCH1010 | ≤300 | ≤30 | 160-200 | 740 | 90 | 6.1 | 2100*2000*1340 |
PCH1016 | ≤300 | ≤30 | 300-350 | 740 | 155 | 9.2 | 2700*2000*1350 |
PCH1216 | ≤350 | ≤30 | 620-800 | 740 | 355 | 15 | 4965*2500*1600 |
PCH1322 | ≤400 | ≤30 | 800 | 595 | 400 | 24.9 | 6333*3295*250 |
