Construction waste, cobblestone, iron ore, manganese ore, river pebbles, granite, limestone, river stone, aluminum ore, etc.
The three-combination mobile crushing station can not only meet the needs of customers for output and movable operations, but also provide a variety of unit configurations according to the actual working conditions of customers. utilization rate and reduced investment costs. The configuration can also be flexibly adjusted according to customer needs.
The vehicle structure is compact.
It can be directly driven into the site and crushed on site, reducing the transportation link of raw materials.
Integrated operation mode.
According to different raw materials and process requirements, the configuration can be flexibly exchanged without changing the body.
During the operation of the mobile crushing station, the material is evenly transported into the crusher by the feeder. After the impact crusher performs preliminary crushing, a closed-circuit system is formed through the circular vibrating screen to realize the cyclic crushing of the material. The finished material is output by the conveyor for continuous continuous crushing.
CHAT ONLINE
Model | Corollary equipment | Corollary equipment | Overall dimensions(mm) | ||
|
| Model | Input size(mm) | Capacity(t/h) |
|
S-PF1214-S18 | 3YZK1860 | PF1214 | ≤300 | 100-200 | 16400 x 2810 x 4500 |
| ZSW9638 |
|
|
|
|
S-PF1315-S21 | 3YZK2160 | PF1315 | ≤350 | 130-280 | 16900 x 3000 x 4500 |
| ZSW4211 |
|
|
|
|
S-LF150-S18 | 3YZK1848 | LF150 | ≤600 | 90-200 | 14800 x 2710 x 4500 |
| ZSW9638 |
|
|
|
|
S-LF250-S21 | 3YZK2160 | LF250 | ≤800 | 180-250 | 16000 x 3000 x 4500 |
| ZSW4211 |
|
|
|
|
S-PCZ1308-S18 | 3YZK1860 | PCZ1308 | ≤500 | 100-160 | 13800 x 2500 x 4200 |
| ZSW9638 |
|
|
|
|
S-PCZ1512-S22 | 3YZK2260 | PCZ1512 | ≤700 | 200-350 | 15000 x 3000 x 4500 |
Model | Corollary equipment | Corollary equipment | |||
|
| Model | Input size(mm) | Capacity(t/h) |
|
S-PF1214-S18 | 3YZK1860 | PF1214 | ≤300 | 100-200 | 16400 x 2810 x 4500 |
| ZSW9638 | ||||
